3.1 RACING AMPLIFIER
Racing amplifier
AMPLIFIER – FOR ON-BOARD COMBUSTION ANALYSIS
The AVL MiniAmp is a miniaturized charge amplifier for combustion monitoring
and control tasks in racing applications.Benefiting from the well known experience
with amplifiers for research and development tasks, the MiniAmp R4 has a tailored
design, especially compact dimension and low weight in racing environments.
AVL MiniAmp
GAIN MAXIMUM POWER by going
to the limit – without going into
extreme knocking!
• Miniature design
• Precise onboard measurement
• Continuous drift compensation
• Galvanic isolated signal and
power lines
without: with AVL MiniAmp:
