A COMMITMENT TO EXCELLENCE
At AVL we always keep the user in mind when we’re designing our products,
and our SlimLine Dilution Systems are no exception. Fold-out parts,
front access and removable covers make maintenance and servicing easy,
and reduced noise output makes life more comfortable for the engineer.
But this commitment to usability, customer experience and satisfaction does
not come at the expense of technological excellence. Indeed, these elements
are two sides of the same coin.
Behind the compact, user-friendly exterior, AVL SlimLine Dilution Systems
now offer enhanced test performance. Extended CVS flow rates of up to
40 m³/min allows the testing of high performance engines or heavier vehicles,
such as pickup trucks. Faster evacuation and purge times improve system availability,
while ISO 17025 and Japan Quality Assurance Organization (JQA)
compliance supports R&D and global emission certification applications.
AVL AMA SL™
• Measures THC, CH4, NO, NOX,
CO2, CO and CO2-Tracer
• TWIN FID for simultaneous
measurements of THC from
the dilution tunnel and CH4
from the bags
• Low sample gas flow enables
smaller bag volumes
instrumentation and test systems
CONSUMING 40 %
LESS ENERGY
IN A CABINET UP
TO 70 % SMALLER,
THE AVL SLIMLINE
DILUTION SYSTEMS
OFFER A HOST
OF BENEFITS FOR
YOUR EMISSION
TESTING.
AVL CVS SL™
• Extended CVS flow rates (up to
40 m³/min) for high performance
vehicles or heavy-duty engines
• Faster and parallel analysis cycles
due to smaller bags
• Improved venturi switching time
due to fast-acting pinch valves
• Flexible location of CVS inlets
and outlets
AVL PSS SL™
• Avoidance of condensation by
heating the particle filter holders
• Rotary valve for filter selection
with integrated shut-off function
• Energy saving through recovery
of waste heat from the vacuum
pump
THREE COMPACT,
POWERFUL TOOLS
The SlimLine Dilution Systems
consist of the following systems,
all of which bring value to the test
cell beyond their initial investment:
4 1
2 0 1 9
AVL CVS SL™ double bag cabinet
for up to 12 bags
Exchanging a filter holder in the heated
compartment of the AVL PSS SL™
SlimLine (left) vs.
conventional
systems (right)
