F O C U S 2 9
HIGH VOLTAGE FOR MORE POWER
AT LOWER CURRENTS
NEXT GENERATION TESTBED
AUTOMATION
AVL PUMA Open 2™ supports
you in every step of your electric
vehicle (EV) development process:
• Unique & intuitive UX
• Ready for MS Windows 10
• Decades of experience in test
automation
AVL’s testbed automation system
offers integrated concepts and
holistic solutions to provide customers
with state-of-the-art technology.
The electrification of powertrain
and alternative fuel systems
as well as the increasing complexity
of powertrain development can
easily be overcome and tested with
AVL PUMA Open 2™. <
Test inverters quickly, precisely
and easily with the e-motor emulator.
AVL’s inverter test system revolutionizes
the testing of drive inverters:
one single application allows
complete coverage of all test
requirements in the development
process reducing testing effort by
more than 90%.
The e-motor emulator and technological
heart of the inverter test system
is a “virtual” e-motor mimicking
e-motor features in static and
dynamic driving scenarios. Key to
this technology is the precise imitation
of the e-motor on the basis
of mathematical models allowing
the testing of inverter and controls
performance – without real motor,
without mechanics, and regardless
of e-motors and testbeds. <
The AVL E-STORAGE BTE™
is a battery tester and/or battery emulator
(simulator) to validate and test
batteries and e-drive components in
real-world operating conditions.
Supporting the new trend of optimizing
the power of batteries
and powertrain components
via an increase of the operating
voltage, AVL introduces the new
AVL E-STORAGE BTE™ 1200V.
It is an enhanced system that can be
used to test components or whole
powertrains at an output voltage of
up to 1200V. The main target of increasing
the voltage level is to achieve
higher power with lower current.
This enables a reduction of the component’s
weight and therefore, the
overall weight of the vehicle.
Due to the patented architecture, the
AVL E-STORAGE BTE™ 1200V
can reach higher voltage levels while
still maintaining outstanding dynamic
performance and highest measurement
and control accuracy. <
>
AVL E-STORAGE BTE™ – Join us in exploring
new e-horizons
From virtual …via E-Drive Testing …and E-Integration Testing
…to the vehicle
>
AVL PUMA Open 2™ – The ease of automation
Discover AVL PUMA Open 2™
www.avl.com/pumaopen2electrifies
INVERTER TEST
SYSTEMS
>
AVL Inverter Test Systems – E-Motion Inverted
